X-ray aprons

GET OPTIMAL ALL-ROUND PROTECTION, NOW MADE EASY.

Optimal protection all round! Thanks to the patented Balance RA631 coverall series, you can get through your working day with greater peace of mind. Special features distinguish this model significantly from other two-piece coveralls.

Fully overlapping front panels achieve lead equivalents of Pb 0.25 mm, Pb 0.35 mm or Pb 0.50 mm at the front and create the conditions for the amazing wearing comfort of the RA631 series: optimum weight distribution, high material suppleness and flexibility.

The integrated, colour-contrasting safety zones provide ideal radiation protection. These give you the certainty of being optimally protected in all situations. The vest and skirt are each equipped with the full lead equivalent of the front section over a width of 12 cm on the sides. When the front wing is within this clearly recognisable zone when the protective clothing is closed, you are covered for the full 60% of your body circumference with the maximum protection value.

In addition to the high-quality Velcro fastener, the skirt has a wide webbing belt. An elastic insert in the back makes it easy to maintain posture and can be easily replaced if necessary thanks to a zip fastener.
The webbing belt provides support without constricting and also ensures an optimal and secure fit.

GET OPTIMAL ALL-ROUND PROTECTION, NOW MADE EASY.

Heavy all-round protection variants place considerable physical strain on the user. We have succeeded in counteracting this with the development of this X-ray protection coat – the patented Synergy RA632 series.

Its comfortable and uncomplicated fit is another special feature. The gown is simply closed with a Velcro fastener at chest height and fits correctly straight away. The required front protection from side seam to side seam is achieved with overlapping front panels.
The required front protection from side seam to side seam is achieved with overlapping front panels. The RA632 series creates the necessary safety zones through a double-layer construction in sensitive areas.

If the front flap is within this clearly recognisable zone when the protective clothing is closed, you cover the full 60% of the body circumference with maximum protection.

An elastic belt (included) provides shoulder relief without uncomfortable constriction. A variable press stud placket on the belt ensures optimal alignment with your waist height. It can be buttoned to the coat on either one or both sides. The coat is also secured with a snap fastener at the bottom.

All-round protection: vest specially designed for the female figure

The Victoria collection is an innovative X-ray protection range that takes the female anatomy into account.
With specially adapted armholes,
the Victoria RA631 vest offers ideal protection for sensitive breast tissue without compromising freedom of movement. Princess seams (longitudinal seams for a close-fitting cut) on the front ensure an ideal fit, while a stretch insert in the back area ensures an optimal fit.

The future of X-ray protection – developed by women for women: discover the perfect balance of comfort and functionality. Put your trust in the Victoria collection – a protective shield that perfectly combines safety and aesthetic design.

The most important advantages at a glance:

• Increased protection with the Levio Edition
• Optimised armholes
• Division seams in the front section
• Stretch insert

All-round protection: This radiation protection gown has been specially designed for the female figure. The gown is easily fastened with Velcro and fits correctly straight away.

• Radiation protection coat specially designed for women
• Ideal fit, maximum comfort
• No full overlap required at the front
• Continuous support thanks to the elastic stretch belt (width 10 cm, included in delivery)
• Shoulder pads as standard equipment
• PFC-free outer material
• Phthalate-free protective materials with recyclable lead content

Advantages at a glance

• Parting seams in the front section – for a good fit but with full radiation protection
• Optimised armholes – ideal protection for sensitive breast tissue
• Stretch insert – for a comfortable fit

FRONT PROTECTION IN ITS PUREST FORM.

The classic – the Basic RA640 model has proven itself over many years and is generally used as front protection for short and infrequent periods of wear in conventional X-ray examinations without fluoroscopy.

The front protection apron is also well suited as protective clothing for accompanying persons. The cut takes into account all requirements in conventional radiology.

FRONT PROTECTION IN ITS PUREST FORM.

Contemporary user protection for a wide range of applications that can also be performed while seated: In practical terms, this means that a front protection apron designed as a functional one-piece garment naturally provides ideal radiation protection in any working position.

Radiation protection aprons are already standard equipment in various specialist areas, such as urology, anaesthesiology, etc. However, the front protection aprons currently in use are designed for standing applications. But in the examples mentioned above, some interventions are performed while seated. When using a regular front protection apron, this carries the risk that the
gonads are exposed to a significantly higher radiation dose than when standing.

The main reason for this is the radiation protection gap that is created when the apron rests on the knees.

Protection specifically for seated activities

To ensure adequate protection even when seated, gonad protection has been added to the inside of the apron. This hangs protectively in front of the gonads while the apron rests on the legs.

At the same time, the new design prevents the apron from slipping down from the legs and resulting exposure. The larger side wings in the lower area keep the apron in position even when moving.

Even when standing, the RA641 ensures complete radiation protection from the neck to below the knees. The side wings in the lower part of the apron can be easily fastened together at the back,
so that they do not interfere with movement and you can work without restriction.

For optimised wearing comfort, the RA640 model is now also equipped with shoulder pads as standard.

FRONT PROTECTION IN ITS PUREST FORM.

Front protection in its purest form – this includes full-surface protection across the entire front section and for the upper back section below the shoulder seam.

To reduce the weight of the apron, you can optionally choose “without protection” in the back section.

For optimised wearing comfort, the RA650 model is now also equipped with shoulder pads as standard.

Comfortable, wide cross straps allow the apron to slide easily through the sterile surgical gown by simply opening the Velcro fasteners at the front.

FRONT PROTECTION IN ITS PUREST FORM.

Contemporary radiation protection clothing that accompanies your active working day with outstanding quality.

Our customers declare this model to be their favourite among the front protection aprons, as it is characterised by comfortable donning and doffing, an ergonomic fit, good fit and shoulder relief.

The wide stretch insert on the back wings enhances the exceptional comfort of the Comfort RA660 model series.

Special features

The wide stretch insert in the back wings ensures individual adjustment, a good fit and shoulder relief, even when wearing X-ray protective clothing for long periods of time.

Thyroid sternum protector with press stud fastening, suitable for all MAVIG model series.

The thyroid gland is an organ of the human body that is sensitive to radiation and therefore requires special protection. Wearing appropriate protection during high-dose examinations should therefore always be a matter of course.

Our version of the thyroid and sternum protector is characterised by its first-class cut and excellent fit, naturally taking all aspects of radiation protection into account.

Equipped as standard with a permanently sewn-in Velcro fastener at the neck, the thyroid and sternum protection is also available with an optional replaceable Velcro fastener or a practical magnetic fastener.

Velcro fastener

magnetic closure

Replaceable Velcro fastener

SHOULDER X-RAY PROTECTION

Thanks to the newly developed bolero as an alternative to sleeves, the radiation exposure from scattered radiation to the shoulder joint can be significantly reduced.

The Bolero shoulder protector is available for all models and is therefore ideal for combination with MAVIG all-round protection or front protection aprons. It is worn directly under the X-ray protection and is easily fastened at the front with a Velcro fastener.

The design, which is open under the arm, allows for maximum freedom of movement.

At the same time, the design significantly reduces the scattered radiation entering from the sides above the armholes. The standard lead equivalent is 0.25 mmPb. This ensures good mobility in daily work routines.

The shoulder protection is always manufactured in the colour “titanium”. The correct size and protective material correspond to the selected X-ray protective clothing.

“M by MAVIG” is the reduced product line of MAVIG X-ray protective clothing for users. With the “M” selection (3 models, 4 lengths, 4 colours, 5 sizes and accessories), you can quickly find effective radiation protection for any work area.

• MPure: lightweight lead-containing material, radiation protection across the entire X-ray tube voltage range of 50-150 kV, best possible combination of weight and radiation protection
• MFree: extremely lightweight lead-free material, optimised for long wearing times, radiation protection across the entire X-ray tube voltage range of 50-110 kV
• MTex: durable, easy-to-clean nylon fabric, special PU coating
• Colours: Inky Blue, New Red, Green 17, Modern Grey
  MCert: Compliant with standards

RA431 All-round protection costume (waistcoat & skirt)

All-round protection with ergonomic comfort thanks to the waistcoat and skirt design

• MPure or MFree
• Particularly suitable for long periods of wear
• Body-contoured cut
• Weight relief for the spine
• Shoulder pads as standard equipment

RA432 All-round protection coat

All-round protection for quick donning thanks to the one-piece design

• MPure or MFree
• Full lead equivalent in both front wings, no full-surface overlap necessary
• Effective shoulder relief thanks to the elastic, replaceable stretch belt
• Ergonomic cut
• Well suited for long periods of wear

RA460 Front Protection Apron

Lightweight front protection for applications with radiation exposure from the front

• MPure or MFree
• Snap buckle closure at the front for easy fastening
• Breathable mesh back wings
• Shoulder pads as standard equipment

RA410 Head Protection

Radiation protection hood to protect the skull

• Breathable mesh upper section
• One size fits all: suitable for all head circumferences from 54-63 cm
• Available exclusively in Modern Grey

RA414 Sternum Protection

Thyroid sternum protection to protect the thyroid gland, which is particularly sensitive to radiation.

• Easy to put on with Velcro fastening.
• One size fits all: suitable for all neck sizes from 32-48 cm.
• Compatible with all “M” products.
• Available exclusively in Modern Grey.

RA437 Shoulder Protection Bolero

Radiation protection for the shoulder joint and chest without restricting freedom of movement.

• Separate radiation protection compatible with all models.
• Closes with Velcro fastening at the front.
• Sizes match the X-ray protection apron.
• Available exclusively in Modern Grey.

Accessories:

AW106 Special bracket

AW415 Wall system

AW425 Mobile system

SHOULDER RELIEF FOR X-RAY PROTECTION APRONS.

Wearing a BRYGGA shoulder bridge under your X-ray protection apron is an easy and effective way to reduce the weight load on your shoulders and prevent muscle fatigue.

The patented invention from Sweden reduces pressure on the shoulder area, which is normally caused by the weight of the apron being worn, in a unique way.

BRYGGA distributes the weight more evenly and relies primarily on the bone structure rather than the muscles and nerve strands. This proves to be particularly advantageous when wearing the apron for long periods of time.

Product features:

• Patented solution
• Recommended for use with MAVIG apron models RA631 and RA632
• Does not interfere with or disturb the user in any way
• Promotes an ergonomically correct posture
• Significantly reduces the risk of tension headaches and numbness in the arms
• Full freedom of movement for the neck and arms
• Easy to clean (just wipe with a cleaning agent)
• Available in sizes S/M and L
• Easy to adjust
• Very comfortable

HIGH PERFORMANCE IN RADIATION PROTECTION

Quality requirements for X-ray protective clothing are more important today than ever before. The wearing time of protective clothing is extended by modern, radiologically supported procedures in diagnostics and therapy, and the protection requirements vary greatly depending on the intended use.

INTERIOR MATERIAL

Standard lead radiation protection
The high-quality, flexible standard lead material based on natural rubber offers radiation protection across the entire X-ray tube voltage range of 50-150 kV, making it suitable for applications in CT, for example.

NovaLite® radiation protection
This first-class radiation protection material achieves an outstanding rating in terms of weight orientation and radiation protection properties. The X-ray tube voltage range for NovaLite material is 50-110 kV.

Lead-free radiation protection
Lead-free is a new, weight-optimised material in which lead has been replaced by bismuth and other radiation-absorbing additives with a lower specific weight. The Leadfree material is also approved for an X-ray tube voltage range of 50-110 kV.

EXTERNAL MATERIAL

ComforTex® HPMF Hybrid
Our ComforTex HPMF Hybrid combines maximum comfort with optimal hygiene and cleaning properties. Thanks to its new special coating, the outer surface offers significantly improved hygiene and cleaning properties. This makes our hybrid material particularly suitable for areas with high levels of liquids. It also offers safety and protection against electrostatic charges, which can interfere with the proper functioning of sensitive medical equipment.

ComforTex® HPMF
Whether as the base material for our hybrid version or as the entire surface for your X-ray protective clothing, the proven ComforTex HPMF is of course still available.

ComforTex® HPMF Plus with image motifs
The new, easier-to-clean outer material, which is also suitable for printing the new Nautilus and Happy fabric designs. At the same time, the surface on the outside of the protective clothing has significantly improved hygiene and cleaning properties thanks to special coatings. That is why our Plus material is particularly recommended in areas with high fluid exposure.

UNTERSCHIED HPMF & HPMF HYBRID

ComforTex HPMF Plus

Happy

Nautilus

CUSTOM-MADE TO YOUR PERSONAL BODY MEASUREMENTS

Using the data sheet below and a standard tape measure, you can easily record your body measurements, which MAVIG will then use to tailor your personal X-ray protective clothing.

Before you put on the tape measure, please note the following: The table data refers to body measurements, which you should measure loosely, without adding extra width but also without constricting yourself.

According to RöV and DIN EN 61331-3, the length of X-ray protective clothing should be such that the front of the body is covered from the base of the neck to at least the kneecaps.

(MAVIG recommends choosing a length that covers the knees for complete protection.)

Dimension sheet for custom-made products
